Product Characteristics
Right-angle downward output structure
WPDX adopts flange input layout with solid output shaft downward. The cast iron housing is thickened with reinforcing ribs; letter X stands for enhanced rigidity variant, effectively avoiding housing deformation under heavy load, perfectly matching vertical installation with limited space.
Single-stage worm & worm wheel transmission
The worm is made of carburized quenched 45# steel, paired with tin bronze worm wheel for smooth meshing. Single-stage reduction ratios range from 10 to 60, realizing large speed reduction with compact monoblock structure without multi-stage gears.
Self-locking performance
The lead angle of the worm is smaller than equivalent friction angle, delivering reliable reverse self-locking after shutdown. It eliminates extra brake parts, ideal for lifting and conveying machinery to prevent slipping.
Product advantages
Smooth & low-noise operation
Flexible meshing between bronze wheel and steel worm minimizes vibration and impact. Running noise is much lower than hard-tooth gearboxes, meeting silent operation requirements of food, packaging and automation equipment.
High load capacity & long service life
Integral cast iron casing and reinforced bearing seats strengthen overall rigidity. Bronze wheel features excellent wear resistance and anti-fatigue performance, extending service life under dusty and humid industrial conditions.
Wide motor compatibility with direct mounting
Standard IEC input flange allows direct connection with 3-phase induction motors and servo motors. Sizes from 40 to 250 cover power range 0.18kW–15kW, no extra adapter plate needed for quick installation.
Product detail photos
WP Series Product Detail Photos
Product Description
Partial drawing display
Product details display
Our advantages
Eight reasons to choose us
We have our own factory
Multiple certificate certifications
Customizationand selection Steps
Payment and Price Terms
Production and testing
Packaging and transportation
Signing for receipt and after-sales service
FAQ
Q:What lubricant should be used for WPDX, and how often to replace oil?
A: Special extreme-pressure worm gear oil is mandatory. For 24h continuous operation, replace oil every 3–6 months; for 8h intermittent use, change lubricant every 6–12 months; shorten cycle under high-temperature environment.
Q: What machines are WPDX gearboxes suitable for?
A: Packaging conveyors, small lifting platforms, mixers, woodworking machines, ceramic processing equipment, automated positioning machines and low-speed high-torque auxiliary plastic molding machines.
Q: What is the warranty period? Is OEM customization available?
A: Standard warranty is 12 months. Customization is supported on reduction ratio, output shaft length, flange size, surface coating color, and customer brand logo printing.
