10W Brushed DC Motor with Gearbox is a medium-sized universal DC geared power unit. It features a 45mm motor diameter matched with 60-series square gearboxes. With wide coverage of voltage and gear ratio options plus customizable output shafts, it delivers sufficient low-speed torque and serves various medium and small automated transmission equipment.
Full range of specifications & high customization flexibility
A wide range of models of 10W brushed DC gear motors are available with customizable no-load speeds, DC voltages and reduction ratios. The output shafts can be manufactured in various types including round shafts, keyway shafts, gear shafts and spline shafts to meet the assembly requirements of diverse equipment.
Standard 45mm motor body & 60-series square gearbox
10W Brushed DC Motor with Gearbox. The motor body has a diameter of 45mm. The matched gearboxes come in two standard sizes: 6060mm and 6070mm. The square housing enables easy installation and fixing, featuring a compact structure that saves space.
Wide voltage compatibility & stable 10W power output
Supports multiple DC voltage ranges from 12V to 310V with a constant rated power of 10W. It features stable internal winding technology and multiple speed versions for selection, suitable for industrial power supply scenarios with high and low voltages.
Wide gear ratio range for flexible torque adjustment
10W Brushed DC Motor with Gearbox features a gear reduction ratio ranging from 1/3 to 1/1296, enabling multiple power output modes including high speed with low torque and low speed with high torque, and accommodating both high-speed pushing and heavy-load low-speed transmission working conditions.
Strong universal mounting & easy assembly
10W Brushed DC Motor with Square Gearbox. The gearbox is pre-drilled with standard mounting holes and features multiple output shaft configurations that can directly connect to customers' transmission assemblies without extra adapter parts, cutting equipment processing costs.
Wide application & stable operation
Brushed drives feature simple control, wide voltage compatibility with both civil and industrial DC power supplies, low jitter during constant-speed operation, and outstanding durability under long-term light and medium load conditions.
Product Photo
|
10W Brushed DC motor with gearbox |
|
|
Motor diameter |
45mm |
|
Speed options |
1500rpm 2000rpm 2500rpm 3000rpm 4000rpm |
|
Power range |
10W |
|
Output shaft types |
Round shaft, keyway shaft, pinion shaft, spline shaft, etc. |
|
Voltage range |
12V 24V 36V 48V 90V 180V 220V 310V |
| Gearbox Diameter | 60*60mm / 60*70mm |
|
Gearbox Ratio |
1/3 ~1/1296 |
|
Place of Origin |
China |
|
packaging |
Wooden box/Carton |
|
HS code |
8501320000/8501310000 |
Q: What is the diameter of this 10W geared motor?
A:The motor body diameter is 45mm, and matching gearboxes are 6060mm or 6070mm.
Q:What DC voltages are available?
A:Standard voltages: 12V, 24V, 36V, 48V, 90V, 180V, 220V, 310V.
Q:What is the range of gearbox reduction ratios?
A:Reduction ratios range from 1/3 to 1/1296, all ratios are available for selection.
