Products Introduction
15W Brushless Worm Gear Motor integrates BLDC motor and worm reducer with low-voltage DC supply. The 90° right-angle layout saves mounting space, built-in self-lock holds load when power off. Brushless structure ensures low noise and long lifespan, suitable for gates, medical devices and small conveyors. Custom gear ratio and wire length are available.
Product Characteristics
90-degree vertical output
The motor spindle and output shaft are arranged perpendicularly at 90 degrees with an integrated L-shaped structure, which fits the limited installation space of compact equipment and supports horizontal, side-mounted and vertical installation modes.
Worm self-locking transmission
The 15W Brushless Worm Gear Motor adopts a worm and worm wheel meshing transmission structure. It features stable reverse self-locking capability when the reduction ratio exceeds 20. The load will not slide down after power cut-off, eliminating the need for an additional electromagnetic brake.
Brushless permanent magnet drive
The 15W Brushless Worm Gear Motor is equipped with a built-in permanent magnet brushless stator that eliminates the carbon brush friction structure. Paired with an external driver, it enables stepless speed regulation and supports multiple speed control signal inputs including PWM, 485 and 0-10V.
Product advantages
Low noise & long service life
Brushless design eliminates wear and tear, resulting in low operating noise. Its no-load noise is below 55 dB, with a continuous 24-hour service life of over 10,000 hours, greatly extending the equipment maintenance cycle.
Ultra-compact installation
Brushless design eliminates wear and tear, resulting in low operating noise. Its no-load noise is below 55 dB, with a continuous 24-hour service life of over 10,000 hours, greatly extending the equipment maintenance cycle.
Safe low-voltage operation
Standard DC24V safe low-voltage power supply, 15W low power consumption, balanced temperature rise control, not prone to overheating during long-hour operation, suitable for light-duty indoor automated equipment.
Product detail photos
Product Description
Partial drawing display
Our Advantages
Eight reasons to choose us
We have our own factory
Multiple certificate certifications
Customizationand selection Steps
Payment and Price Terms
Production and testing
Packaging and transportation
Signing for receipt and after-sales service
FAQ
Q: Is a dedicated driver mandatory for the 15W brushless worm gear motor?
A: Yes. Brushless motors cannot run by direct DC power supply. A matched BLDC driver is required to adjust speed, switch rotation direction and activate overload protection.
Q: Will the self-locking function fail under heavy load?
A: Self-locking remains stable with reduction ratio ≥20. If you select small ratio models with overloaded weight, the self-locking performance will decline. High-lifting heavy load applications need high reduction ratio versions.
Q:Can the 15W motor work in damp outdoor environments?
A:The standard model has IP44 protection for dry indoor use only. We offer customized IP65 waterproof versions with anti-rust surface treatment for outdoor and humid conditions.gular maintenance, avoiding overload operation, and maintaining stable voltage can effectively extend the service life.
