Product Characteristics

Constructed entirely from 304 stainless steel

The casing, gears, and key transmission components of our stainless steel gearbox are all machined from high-quality 304 stainless steel, achieving full anti-corrosion coverage from the core structure to the external shell, which is different from the partial anti-rust treatment of ordinary carbon steel gearboxes.

High sealing protection level

Our stainless steel gearbox has an IP69K protection rating, combined with special corrosion-resistant seals and precision assembly technology, it has excellent resistance to water, dust, and corrosion medium penetration, and can meet the sealing requirements of harsh environments such as high humidity and strong corrosion.

Transmission performance and material compatibility

On the basis of using stainless steel material, our stainless steel gearbox ensures transmission accuracy and torque output efficiency through optimized gear tooth profile design and heat treatment process, achieving a dual balance between anti-corrosion performance and mechanical performance.

Product advantages

Extremely strong corrosion
resistance

Our stainless steel gearbox can be directly used in scenarios with acid-alkali media and salt spray erosion, such as chemical industry, marine environment, and food processing. It is not prone to rust, deformation, component failure, etc., which greatly reduces the probability of failures in harsh environments.

Compliance with clean and hygienic standards

The surface of our stainless steel products is smooth and easy to clean, with no risk of coating peeling off and no residual pollutants. They meet the clean production requirements of industries such as food, medicine, and beverages, and have more advantages with relevant health and safety certifications.

Long service life and low operation and maintenance costs

The wear resistance and anti-aging ability of our stainless steel material are better than those of ordinary carbon steel. The failure rate of the equipment during long-term operation is lower. Daily maintenance only requires regular lubrication and cleaning, which reduces the number of shutdowns for maintenance and the cost of replacing parts.

Product detail photos

Product Description

Stainless steel gearbox
Typical Models	Helical Inline Reducer: R37, R47, R57, R67 Helical Bevel Right Angle Gearbox: K37, K47, K57, K67 Worm Gear Reductor: NMRV030, NMRV040, NMRV050, NMRV063, NMRV075, NMRV090, VF040, VF050, VF063
Motor Power	0.09KW 0.12HP, 0.12 KW 0.18HP, 0.18 KW 0.25HP, 0.25 KW 0.33HP, 0.37 KW 0.5HP, 0.55 KW 0.75HP, 0.75KW 1HP, 1.5 KW 2HP, 2.2 KW 3HP, 3.7 KW 5HP, 4 KW 5HP, 5.5 KW 7.5HP, 7.5 KW 10HP, 11 KW 15HP, 15 KW 20HP, 18.5 KW 25HP, 22 KW 30HP
Input Speed	750rpm 900rpm 1000rpm 1200rpm 1500rpm 1800rpm 3000rpm 3600rpm
Reduction Ratio	1/5 1/7.5 1/10 1/15 1/20 1/25 1/30 1/40 1/50 1/60 1/80 1/100, etc.
Input Motor	AC IEC or NEMA (1 phase or 3 phase), DC
Output Type	Hollow shaft, solid shaft, flange
Housing Material	304 or 316 food-grade material
Dimension Standard	Metric size / Imperial size
Lubrication oil	Food grade oil
Accessories	Input flanges, Output flanges, Solid output shaft, Torque arm, etc.
Input flange options	56B5, 63B5, 63B14, 71B5, 71B14, 80B5, 80B14, 90B5, 90B14, 100B5, 100B14, 112B5, 112B14, 132B5
Origin	Zhejiang, China
Warranty	1 year
Application	Food Stuff, Ceramics, Chemical, Packing, Dyeing, Woodworking, Glass, etc.
Package	carton/wooden box
HS codes	8483409090
