90W Brushless Worm Gear Motor is reinforced 90-frame right-angle BLDC gear reducer, running at 1400-3000rpm with ratios 1/5~1/100, solid or hollow output shaft optional. It supports wide DC voltage 12V-310V with optional driver, brake and encoder. As the top-power model of 90mm series, it delivers abundant heavy-load torque and reliable self-locking, ideal for heavy-duty lifting and conveying automation equipment. It has 1-year warranty with carton or wooden box packaging.
Thickened 90mm Heavy-Duty Frame
The housing of the 90W worm gear motor is thickened, and the size of the worm and worm wheel pair is enlarged. Its mechanical rigidity far exceeds that of low-power motors with a 60 frame size, delivering stronger shock resistance.
Full Span Speed Ratios
90W Brushless DC Worm Gear Motor with a full gear ratio range from 1/5 to 1/100, capable of both high-speed rapid rotation and outputting ultra-high torque at low speeds.
Full Wide Voltage Compatibility
The 90W Brushless Worm Gear Motor is compatible with 12V low-voltage lithium battery equipment and 310V industrial high-voltage DC power supplies, and customized non-standard special supply voltages are available.
Maximum Continuous Torque in Same Frame
Rated power of 90W under the 90mm body, with superior continuous load capacity compared to 60W models of the same specification, capable of stably driving heavy loads for long-term operation.
All-in-one Modular Optional Functions
Free combination of drive, brake and encoder accessories for the 90W Brushless Worm Gear Motor; a single motor integrates all functions including stepless speed regulation, precise positioning and power-off self-locking.
Dual Protective Shipping Packages
Cartons are used for sample orders to cut logistics costs, while wooden cases with reinforcement are adopted for bulk exports to prevent bumping and damage during long-distance ocean shipping.
Q: What material is the worm wheel of this motor? How about its wear resistance?
A: Standard tin bronze worm wheel with low friction, quiet operation and great wear resistance for long continuous running.
Q: How to solve severe jitter when starting/stopping the 1/100 low-speed model?
A: Match an external driver with soft-start function to smooth low-speed start and stop and eliminate jitter.
Q: Can the motor be installed vertically upside down, horizontally or at any angle?
A: Multi-angle installation is available. Just ensure proper gear oil level; customized oil seal is available for upside-down installation on request.
