Product Characteristics
Wide And Precise Speed Regulation Range
Our variable speed gearbox can achieve stepless or multi-stage speed regulation within a set range according to the operation requirements of the equipment. Equipped with high-precision transmission gears and adjustment mechanisms, it can accurately match the changes in load speed and adapt to speed control requirements under different working conditions.
Strong Transmission Adaptability
Our product supports flexible connection with various power sources (such as motors, internal combustion engines) and actuators (such as pumps, fans, conveyors). By adjusting the gear meshing ratio, it can output different torques and speeds without changing the input speed of the power.
Structural Modular Design
The core components of our UDL gearbox adopt a standardized and modular structure. Different functional modules (such as brake modules, lubrication modules) can be selected according to actual needs. The installation and disassembly are convenient, which is conducive to later function upgrading and transformation.
Product advantages
Wide And Precise Speed Regulation Range
Our variable speed gearbox can achieve stepless or multi-stage speed regulation within a set range according to the operation requirements of the equipment. Equipped with high-precision transmission gears and adjustment mechanisms, it can accurately match the changes in load speed and adapt to speed control requirements under different working conditions.
Strong Transmission Adaptability
Our product supports flexible connection with various power sources (such as motors, internal combustion engines) and actuators (such as pumps, fans, conveyors). By adjusting the gear meshing ratio, it can output different torques and speeds without changing the input speed of the power.
Structural Modular Design
The core components of our UDL gearbox adopt a standardized and modular structure. Different functional modules (such as brake modules, lubrication modules) can be selected according to actual needs. The installation and disassembly are convenient, which is conducive to later function upgrading and transformation.
Product detail photos
Product Description
|
Models |
Power |
Ratio |
O. Speed |
O.Torque |
O. Shaft Dia. |
O. Flange Dia. |
|
UDL002 |
0.18KW |
1.6~8.2 |
800~170rpm |
1.5~3N.m |
Φ11 |
Φ140 |
|
UDL005 |
0.25KW |
1.4~7 |
1000~200rpm |
2.2~6N.m |
Φ14 |
Φ160 |
|
UDL005 |
0.37KW |
1.4~7 |
1000~200rpm |
3~6N.m |
Φ14 |
Φ160 |
|
UDL010 |
0.55KW |
1.4~7 |
1000~200rpm |
4~8N.m |
Φ19 |
Φ200 |
|
UDL010 |
0.75KW |
1.4~7 |
1000~200rpm |
6~12N.m |
Φ19 |
Φ200 |
|
UD020 |
1.1KW |
1.4~7 |
1000~200rpm |
9~18N.m |
Φ24 |
Φ200 |
|
UD020 |
1.5KW |
1.4~7 |
1000~200rpm |
12~24N.m |
Φ24 |
Φ200 |
|
UD030 |
2.2KW |
1.4~7 |
1000~200rpm |
18~36N.m |
Φ28 |
Φ250 |
|
UD030 |
3.0KW |
1.4~7 |
1000~200rpm |
24~48N.m |
Φ28 |
Φ250 |
|
UD030 |
4.0KW |
1.4~7 |
1000~200rpm |
32~64N.m |
Φ28 |
Φ250 |
|
UD050 |
5.5KW |
1.4~7 |
1000~200rpm |
45~90N.m |
Φ38 |
Φ300 |
|
UD050 |
7.5KW |
1.4~7 |
1000~200rpm |
59~118N.m |
Φ38 |
Φ300 |
Partial drawing display
Eight reasons to choose us
We have our own factory
Multiple certificate certifications
Customizationand selection Steps
Payment and Price Terms
Production and testing
Packaging and transportation
Signing for receipt and after-sales service
FAQ
Q: Do you provide sample lists?
A: Yes, we support purchasing sample orders for testing.
Q: How to pay the money?
A: T/T is preferred, with different currencies, including USD, EUR, RMB, etc.
Q: How shall we contact you?
A: You can send an inquiry directly, and we will respond within 24 hours.
