Product Characteristics
High Torque
Our planetary gearbox adopts a double-supported structure output shaft, which greatly increases the allowable torque of the whole machine under load.
High Load Capacity
Our gearbox features a two-stage spur gear design with a large modulus and high torque-bearing capacity. The medium-hard tooth surface gear processing technology ensures the gear's strength, toughness, and wear resistance.
Low Noise
The input stage of our product adopts a helical gear design, which makes the gearbox transmission more stable and reduces noise at high speeds.
Product advantages
More Reliable
Our product uses a spline connection between the sun gear and the planet carrier, which greatly enhances the transmission torque of the internal gears and effectively ensures the connection reliability under high torque.
Long Service Life
The inner hole of our planetary gear adopts a planetary cage structure, which converts sliding friction into rolling friction, thereby extending the service life and improving efficiency.
High Precision
The inner hole of our planetary gear is processed by grinding technology, with a surface hardness of HRC60 and a cylindricity of less than 0.003mm.
Product detail photos
Product Description
|
Precision Planetary Gearbox |
|
|
Model |
40-220 |
|
Ratio |
1/3 ~ 1/512 |
|
Efficiency |
98% |
|
Housing material |
42CrMo |
|
Gear material |
20CrMnTi |
|
Type |
Coaxial or Right angle |
|
Torque |
40-3000Nm |
|
Input/Output shaft material |
40Cr |
|
Machining precision of gears |
6 Grade |
|
Place of origin |
China |
|
Packaging |
wooden box/carton |
|
HS code |
8483402000 |
Partial drawing display
Product details display
Our advantages
Eight reasons to choose us
We have our own factory
Multiple certificate certifications
Customizationand selection Steps
Payment and Price Terms
Production and testing
Packaging and transportation
Signing for receipt and after-sales service
FAQ
Q: Do you provide sample lists?
A: Yes, we support purchasing sample orders for testing.
Q: How shall we contact you?
A: You can send an inquiry directly, and we will respond within 24 hours.
Q: What kind of packaging does the product use?
A: Wooden boxes, cartons, or pallets that meet export packaging requirements.
